Simultaneous measurement of eight components • Automatic comparison of measurement results
Measurement range: (-60~+20) ℃ DP
Maximum allowable error: ±2 ℃ DP
Response time: ≤3min
In the rapidly developing power industry today, precise measurement and analysis of SF6 gas are of great significance. The RA912F SF6 Gas Comprehensive Analyzer (8-in-1) has emerged as a star product that attracts much attention in the market with its excellent intelligent functions and remarkable high - value appearance design.
Multi - functional Integration: The RA912F SF6 Gas Comprehensive Analyzer integrates functions such as humidity and purity detection, as well as analysis of various decomposition products like sulfur dioxide, hydrogen sulfide, carbon monoxide, hydrogen, etc. At the same time, it can also detect the content of carbon tetrafluoride, air or oxygen, truly achieving "8 - in - 1" comprehensive detection.
Dual - channel Automatic Flow Control: It adopts advanced dual - channel automatic flow control technology to ensure the stability and accuracy of the measurement process, providing a solid guarantee for your data analysis.
BPS Battery Power Supply: The innovative BPS battery power supply design enables the device to continue working outdoors or in environments without power supply, meeting the needs of various complex scenarios.
New Standard for Humidity PPMS Conversion: The humidity measurement adopts PPMS conversion technology, which fully complies with the new standard of DL/T 506 - 2018, ensuring the accuracy and reliability of the measurement results.
Trolley - type Waterproof Box Design: The unique trolley - type waterproof box design is not only convenient for carrying and transportation but also effectively prevents water intrusion, protecting the device from damage.
Data Stable Latching: The device can automatically latch stable (or qualified) data, avoiding data loss caused by misoperation and making your work more efficient and convenient.
The RA912F SF6 Gas Comprehensive Analyzer is widely used in the power industry, laboratories, research institutions and other fields. It is suitable for the rapid measurement and analysis of SF6 gas components, providing a strong guarantee for the safe operation of power equipment.
Intelligent Operation: The simple and easy - to - use operation interface allows you to get started easily and improve work efficiency.
High - value Appearance Design: The fashionable and generous appearance design not only enhances the grade of the device but also makes your work more enjoyable.
Professional Service: We provide comprehensive technical support and after - sales service to ensure your worry - free use.
If you are looking for a SF6 gas comprehensive analyzer with comprehensive functions and excellent performance, then the RA912F SF6 Gas Comprehensive Analyzer (8 - in - 1) is definitely your best choice! Contact us immediately to learn more details!
| Parameter Name | Measurement Range | Maximum Allowable Error | Response Time |
|---|---|---|---|
| Humidity Td (Resistance-Capacitance) | (-60~+20) ℃ DP | ±2℃ DP | ≤3min |
| SF₆ purity | (0~100)% (volume ratio) or (90-100)% (volume ratio) | ±0.5% (volume ratio) | ≤40s |
| Air | (0~5000) μL/L (oxygen to air ratio is 21%) | ±2.5%F.S | ≤40s |
| Carbon tetrafluoride (CF₄) | (0~2000) μL/L | ±2.5%F.S | ≤40s |
| Sulfur dioxide (SO₂) | (0~100) μL/L | ±0.5μL/L for 0~10μL/L; ±5% for 10~100μL/L | ≤40s |
| Hydrogen sulfide (H₂S) | (0~100) μL/L | ±0.5μL/L for 0~10μL/L; ±5% for 10~100μL/L | ≤40s |
| Carbon monoxide (CO) | (0~500) μL/L | ±2μL/L for 0~50μL/L; ±4% for 50~500μL/L | ≤40s |
| Hydrogen (H₂) | (0~100) μL/L | ±5%F.S | ≤60s |
